Action Reference

Overview

Studio has 22 actions across 6 categories. The same picker opens for every page lifecycle event (On Screen Load, On Focus, On Blur, On Header Action) and for a component’s own touch events (On Tap, On Long Press, and the rest). Same search box, same six categories, same entries. This page lists what each action takes. For where actions are attached, see the page configuration docs.

How to read these tables

Control is what the parameter renders as in the panel: a text field, a dropdown, or a textarea.
Default or placeholder: a value in code is a real default, meaning the dropdown opens already showing it. A value in italics is a placeholder, which is grey hint text in an empty field. Leave the field alone and the action gets nothing, not the placeholder.
Required?: Studio marks no action parameter as required. There are no asterisks and no red validation, and every action can be left completely unconfigured. Where this column says effectively, that is an inference from the parameter’s purpose, not a label Studio shows.
Bind: most free text parameters carry Var and Bind controls on the label row, for pointing the parameter at a variable or at another component’s value instead of typing a literal.

Action	Parameter	Control	Default or placeholder	Required?	What it expects
Navigate To	Target Page	dropdown	Select page…	effectively	Every page in the project
	Route Parameters	dependent sub-form		no	Inert until a target page is picked, showing Select a target page first. Once a target is chosen it reads No parameters declared on target page. You can add custom params below and offers + Add Parameter
Go Back	(none)				Go Back has no parameters at all. Adding it is the whole configuration
Open URL	URL	text + Bind	https://example.com	effectively	An external URL to open in the browser

Data

Action	Parameter	Control	Default or placeholder	Required?	What it expects
API Call	(unlabelled)	dropdown	Select API call…	effectively	A configured API call, listed from CONNECT → API Calls
	On Success / On Error	nested action branches		no	Each opens the same 22 action catalog, for chaining a follow up action
Set Variable	Variable	dropdown	Select variable…	effectively	The page’s declared variables, each listed with its type, for example `isLoading boolean`. Empty on a page with none
	Value	text, with a Static/Dynamic toggle	new value	no	In the default static mode, a literal typed into the field. The button beside it reads Dynamic, which is the mode it will switch to. Click it and the button reads Static and a Bind control replaces the plain field

The API Call dropdown is gated on having an API call defined, not on having a backend connected. With one call defined and no backend connected, the dropdown lists that call. See Connect an API.

Interaction

Action	Parameter	Control	Default or placeholder	Required?	What it expects
Show Alert	Title	text + Bind	Alert	no	The dialog’s title
	Message	text + Bind	Something happened	no	The dialog’s body text
Show Toast	Message	text + Bind	Action completed	effectively	The toast’s text
	Duration	dropdown	`Short (2s)`	no	Short (2s) or Long (4s). Two options, nothing custom
Haptic Feedback	Style	dropdown	`Selection`	no	Seven: Selection, Impact Light, Impact Medium, Impact Heavy, Notification Success, Notification Warning, Notification Error
Copy to Clipboard	Text	text + Bind	Text to copy	effectively	The string to put on the clipboard
Toggle Overlay	Overlay	dropdown	Select overlay…	effectively	Overlay components placed in the project: Modal, Drawer, AlertDialog, Popover. Zero options if none is placed
	Action	dropdown	`Toggle`	no	Toggle, Open, Close

Communication

Action	Parameter	Control	Default or placeholder	Required?	What it expects
Share	Title	text + Bind	Check this out	no	Title passed to the native share sheet
	Message	text + Bind	Hey, take a look!	no	Body text to share
	URL	text + Bind	https://example.com	no	A link to share
Open Email	To	text + Bind	user@example.com	effectively	Recipient address
	Subject	text + Bind	Hello	no	Subject line
	Body	text + Bind	Message body	no	Body text

Flow

Action	Parameter	Control	Default or placeholder	Required?	What it expects
Run TypeScript	Code	textarea	// your TypeScript code here	effectively	TypeScript source. A plain textarea, not a code editor with syntax highlighting or completion. No Bind control
	On Success / On Error	nested action branches		no	Each opens the full action catalog
Delay	Duration (ms)	text	1000	effectively	A number of milliseconds. No Bind control
Console Log	Message	text + Bind	Debug message	effectively	The message to log

Authentication

Exactly seven Authentication actions exist. All seven open and are fully readable with no backend connected, because the parameter forms are not gated behind a provider. Every one of them also carries On Success and On Error branches.

Action	Parameter	Control	Default or placeholder	Required?	What it expects
Sign In	Email	text + Bind	Bind to the email field	effectively	The email to sign in with. The placeholder is telling you to bind, not to type
	Password	text + Bind	Bind to the password field	effectively	The password
	OAuth Provider	dropdown	`None` (the email and password default)	no	Opens showing two options, Google and Apple. The default text is what the field reads before you pick one
Sign Up	Email	text + Bind	Bind to the email field	effectively
	Password	text + Bind	Bind to the password field	effectively
	Confirm Password	text + Bind	Bind to the confirm field	no
	Display Name	text + Bind	(no placeholder)	no	A name for the new account
Sign Out	(none)				No parameters, only the On Success and On Error branches
Send OTP Code	Phone Number	text + Bind	Bind to the phone field	effectively	The number to text the code to
Verify OTP Code	Phone Number	text + Bind	(no placeholder)	effectively	The same number the code was sent to
	Code	text + Bind	Bind to the code field	effectively	The code the user typed
Send Magic Link	Email	text + Bind	Bind to the email field	effectively	Address to email the one tap link to
Send Password Reset	Email	text + Bind	Bind to the email field	effectively	Address to email the reset link to

Which actions have On Success and On Error

Nine of the 22, and they are exactly the ones that talk to something outside the app.

Has On Success / On Error	Does not
API Call, Run TypeScript, Sign In, Sign Up, Sign Out, Send OTP Code, Verify OTP Code, Send Magic Link, Send Password Reset	Navigate To, Go Back, Open URL, Set Variable, Show Alert, Show Toast, Haptic Feedback, Copy to Clipboard, Toggle Overlay, Share, Open Email, Delay, Console Log

Each branch expands to its own + Add control that opens the same 22 action catalog, so an action chain can nest.

The Bind and Var affordances

Almost every free text parameter’s label row carries two small controls, Var and Bind. Bind opens a Search components… picker listing the page’s own bindable component nodes, by type and node id, each with a count and an expand chevron, such as Button button_1 (3) or Input input_1 (4). This is the same binding vocabulary a component’s own properties use. Three parameters have no Bind control: Run TypeScript’s Code (a textarea), Delay’s Duration (ms), and Set Variable’s Value, which has its own Static and Dynamic switch instead.

What a missing backend actually changes

Not the forms, the option lists. On a project with no backend connected, every Authentication action’s fields sit there ready to be bound to inputs that nothing will authenticate against. Toggle Overlay’s dropdown is empty until an overlay component exists on the page. Set Variable’s dropdown is empty until a variable is declared. The gating is data, not UI. So the presence of an Authentication action in a project says nothing about whether authentication is actually wired.

Troubleshooting

Issue	Likely cause	What to do
An action’s dropdown (API Call, Toggle Overlay, Set Variable) opens completely empty	The dropdown lists project data that does not exist yet	Create the thing first: define an API call, place a Modal, Drawer, AlertDialog or Popover, or declare a Page or App Variable under Properties → Variables
You typed nothing into a field and expected the grey hint text to be used	That is a placeholder, not a default. An empty field stays empty	Type a real value, or use Bind or Var
You cannot tell which parameters are mandatory	Studio marks none of them	Use the Required? column above. Where it says effectively, the action can still be saved without it, it just will not do anything useful
